Description

Application: Junior (12-15) and Senior (15+) 4-Cycle classes (Briggs 206)

Standard Equipment/Features

Chassis

• 1.25″ (32mm) & 1.125 (28mm) multi-alloy construction
• 41.25″ wheelbase
• 10° KPI, 15° caster, adjustable
• Adjustable ackerman
• Adjustable front & rear ride height
• Billet fairing mount/toe lock
• Sniper SA1 linear caster/camber adjusters
• Heat-treated billet 25mm spindles

• 25mm x 95mm euro mount front hubs, billet aluminum
• 40mm rear axle, 2 bearing, adjustable
• 40mm x 65mm euro mount rear hubs, billet aluminum
• 40mm aluminum sprocket hub

• Billet adjustable front torsion
• Billet chain adjuster
• Margay M8 Steering Wheel

• Angled 2 position steering hub

• 8.5L liter fuel tank with integral pick-up & vent

Bodywork

• KG ‘506/Evo-Stilo’ lightweight bodywork; black or red
• KG ‘RS3‘ adjustable full width rear bumper
• Margay factory decal kit

Brakes

• MCP 2 piston caliper – ‘no shim’ gap adjustment
• MCP master cylinder
• 200mm ‘Wave’ rotor
• Braided stainless brake lines

Seat

• G-Seat ES1 fiberglass shell seat
• Adjustable lower mounts
• Fixed position upper mounts

Wheels

• TruSpeed Magnesium front and rear wheels

Available Options

• Caster/camber adjustment pills
• Heat-treated billet 17mm spindles
• 50mm rear axle assembly
• DWT hub mount front wheels
• DWT AlumiLite wheel set
• KG BDE bodywork
• KG Evo bodywork
• G-Seat ES1 fiberglass shell seat – Soft
• G-Seat ES1 fiberglass seat – 1/4 pad
• G-Seat DS1 fiberglass shell seat
• Various stiffness rear axles
• Various length rear hubs
• Various length front hubs
